Ocean-Bottom Seismometers Play Crucial Role in Offshore Sensing

Blue ellipses show where NFSI OBS have been deployed offshore Canada to date. Image from NFSI.

Much of central Canada lies on very old, stable bedrock with little seismic activity. In contrast, the county’s coastlines face far greater seismic risk, particularly (but not limited to) the west coast. Of greatest concern is a major subduction zone off Vancouver Island, where tectonic plates pushing together suggest a large earthquake is due.

Canada is all too familiar with the impact of offshore earthquakes. The magnitude 7.2 Grand Banks earthquake of 1929 triggered one of the most destructive tsunamis ever recorded in the country, devastating coastal communities in Newfoundland and Cape Breton. As a result, Canada’s National Facility for Seismological Investigations (NFSI) was set up in 2021 to investigate, characterize and predict this risk, in Canada and overseas.

Based at Dalhousie University and supported by a partnership of 10 Canadian universities, NFSI was funded through a major Canadian Foundation for Innovation investment with approximately USD$10.77 (C$15 million) allocated for equipment and infrastructure.

Core to this is a national pool of more than 120 broadband ocean-bottom seismometers (OBS). Since operations launched in 2023, around 100 of these have been deployed annually in locations ranging from the Arctic to New Zealand. By placing seismometers directly on the seafloor, researchers can detect much smaller offshore earthquakes and determine their locations far more accurately than is possible using land-based sensors alone.

But positioning them and, crucially, recovering them to download their data, then getting them ready for the next deployment, isn’t simple, especially when locations range from ice-covered Arctic waters to 4,700 m deep abyssal plain. And because the NSFI team relies on diverse “vessels of opportunity," from small fishing boats to ice-rated trawlers and large coastguard ships, and operates with a very small field staff, their choice of underwater positioning also has to be flexible.

Deployment in January in New Zealand. Photo from NFSI.

The ideal scenario, to enable accurate positioning and efficient recovery, is to use a precise Ultra-Short BaseLine (USBL) positioning system. NFSI acquired the Sonardyne Ranger 2 Gyro USBL system for this reason.

Gyro USBL is designed as a pre‑calibrated, all‑in‑one unit, with the acoustic transceiver and attitude and heading reference system (AHRS) factory‑aligned in one housing. This compact configuration removes alignment/lever‑arm errors, reduces setup time and means it can be easily moved from vessel to vessel, with over-the-side pole mounting, for example, without the need for time-consuming calibration routines.

By compensating for vessel motion while providing direction to an instrument as well as distance, Gyro USBL enables quick and precise instrument location on the seafloor and real-time tracking during recovery, allowing vessels to intercept instruments as they surface. This accuracy reduces ship time, lowers operational risk, and ensures reliable data recovery even in Canada’s most hazardous offshore environments.

Due to the range of water depths in which they deploy OBS, NFSI chose an LMF (low medium frequency) version of Ranger 2 Gyro USBL, enabling longer tracking ranges, up to 11,000 m slant range, compared with our standard MF (medium frequency) 7,000 m range.

But when it comes to having to work from a small vessel, or where mounting the Ranger 2 Gyro USBL transceiver isn’t practical, seafloor instruments are positioned by surface triangulation using our directional Modem 6 Dunker. This method uses ranges to the OBS from three of four surface positions (by moving their vessel to different locations), and pressure data from the OBS communicated acoustically, to calculate the OBS’ position, including depth, on the seafloor. To cover all scenarios, NFSI chose a Modem 6 Mini Dunker directional variant, giving it the extra range (to 3,000 m) and more targeted signal strength, helping overcome any ship noise, thanks to its focused acoustics.

A Ranger 2 Gyro USBL head on a over-the-side pole mounting.

Operations during Pacific Coast Seismic Assessment for Faults and Earthquakes (PACSAFE) project. Photo from Geological Survey of Canada.

Operations in Baffin Bay and Labrador. Photos from NFSI.

Following an intensely busy two years, the NFSI team is shifting its focus from rapid data acquisition to strategic international expansion and technological development.

The primary deployment of 2026 will be the TRACE project in May—a broad European collaboration involving French, Italian and Croatian institutes. This “amphibious survey” will deploy 20 instruments across the Adriatic Sea, integrating marine and land-based seismic monitoring with both nodal and distributed acoustic sensing (DAS) cable systems in a new international context.

For the remainder of 2026, NFSI will focus on instrument recoveries and turnarounds rather than new deployments.

Two major international expeditions are under discussion for 2027 or 2028—a large-scale active-source survey on the East Pacific Rise and a significant research campaign off the coast of Chile.

Efforts are also underway to improve the speed of data processing and interpretation, closing the gap between acquisition and analysis.

From ice-covered Arctic waters to abyssal plains, deploying and recovering ocean-bottom seismometers is essential for understanding crustal structure and assessing geohazards. But it only works when teams can pinpoint instruments on the seabed and communicate with them reliably for recovery.

By combining the high-precision Ranger 2 Gyro USBL with the portable Modem 6 Dunker for scenarios where fixed mounting isn’t practical, NFSI builds in operational flexibility.

It can operate from vessels of opportunity while reducing ship time, lowering risk and ensuring dependable data return in some of the world’s most demanding offshore environments.
